The Economic Video Measuring Machine is a cost saving solution that we offered to our customers. The instrument also has good accuracy for the measurement on the 2D dimension. Integrated desk and separated desk are provided for selection.
The cost saving can improve the working efficiency of customers, and make customers have more costs to spend on what they should spend. Instruments are widely used in medicine, aviation, equipment and other industries.
| Category | Parameter |
| Measuring stroke(mm) | 250x150x200 |
| Overall dimension of the instrument (mm) | 860x802x1738 |
| Net/Gross Weight(kg) | 220/330 |
| Load capacity of the worktable (kg) | 30 |
| Measurement resolution | 0.5μm |
| Measurement accuracy | X,Y accuracy:(3+L/200) μm |
| Repeatability | 2μm |
| Operating mode | Manual |
| Magnification | Optical magnification:0.7X-4.5X,image magnification:28X-180X |
| Software | SINPO-M |
| CCD | 470,000 pixel, colorful CCD |
| Power supply | 110-220V |
| Working Environment | Temperature:20±5℃,humidity:45%-75% |
| Light source | Programmable control 3-loop and 8-area LED cold light |
